Product Specifications
- Brand
- Siemens
- Part Number
- 3NJ6900-4HH21
- Type
- Analogue Panel Ammeter
- Series
- SENTRON 3NJ6 accessory range
- Current Rating
- 300 A transformer primary current
- CT Ratio
- 300/5 A
- Measuring Element
- Moving Iron
- Accuracy Class
- Class 1
- Burden
- 0.6 VA
- Overload Capacity
- 2-fold
- Panel Size
- 48×48 mm to DIN 43718
- Net Weight
- 92 g
Product Description
The 3NJ6900-4HH21 is a moving-iron ammeter in the SENTRON accessory range for 3NJ6 in-line switch disconnectors with fuses. Siemens describes it as an ammeter with a moving-iron movement, 300 A over 5 A, class 1 and 0.6 VA, with two-fold overload. It reads the secondary circuit of a 300/5 A current transformer; the 300 A figure is the primary rated current of the transformer feeding it.
The meter fits the NH2 and NH3 sizes of the disconnector range, which correspond to 400 A and 630 A fuses. Smaller primary currents sit with other members of the same accessory family, which runs from 50 A to 600 A in steps that include 100, 150, 200 and 250 A. Each rating comes with a 1 A or a 5 A secondary and in either a moving-iron or a bimetal movement; this part is the 5 A moving-iron version of the 300 A step.
The face measures 48 mm by 48 mm and follows DIN 43718, which defines the panel cutout it drops into. The body fixes by snap mounting, and the assembly reaches the disconnector through a holder ordered separately under part number 3NJ6900-4GA00 for the NH00, NH1, NH2 and NH3 sizes.
Accuracy class 1 applies at a burden of 0.6 VA, and the movement tolerates a two-fold overload. The in-line pluggable format of the disconnector allows an ammeter to be added at any time without switching off the switchboard. The 690 V AC and 440 V DC figures quoted around this family describe the disconnector, with the direct current value requiring the conducting paths in series, and Siemens type-tests the disconnector to IEC EN 60947-3. The meter itself carries no separate voltage or standard entry in the Siemens data sheet, and its net weight is 92 g.
