The Roscid Technologies OxyTrans is an accurate and economic process oxygen transmitter capable of measuring both trace and percent levels of oxygen. Utilizing 4–20mA loop powered, two-wire output, the OxyTrans meets industrial requirements for accuracy, sensitivity, ease of use and operating life.

The OxyTrans is easy to set up and calibrate. The 6 digit, alphanumeric display includes a bar graph for easy viewing of trends. It includes 4 user-selectable trace oxygen ranges (0-10 ppm, 0-100 ppm, 0-1,000 ppm and 0-10,000 ppm) and two percent ranges (0-25% and 0-100%). Accuracies to ±2% can be achieved for samples with a constant temperature, for applications with variable temperatures, accuracies of ±5% can be expected. Calibration of the OxyTrans for percent measurements can be done with air. For trace oxygen measurements in gas, calibrations should be done with a calibration gas.

The OxyTrans utilizes a flow-through measuring cell. The quality stainless steel construction of the transmitter ensures a long sensor life and modular design allows cells to be replaced easily. The electronics are protected with a quality IP65 rated enclosure. An ATEX explosion-proof enclosure is available.

Applications: Semi conductor industry, gas manufacturing, metallurgical industries, chemical industry, heat treating and bright annealing.
