Industrial Probe RTD - -330 to 1100°F | NOSHOK 910/915

1 / 5

Product Specifications

Manufacturer: NOSHOK
Series: 910/915 Series
Product Type: Industrial Probe RTD
Temperature Ranges: -50 to 400°F, -50 to 750°F, -330 to 1100°F
Element: PT100 Ω @ 32°F, α=0.00385 IEC 751
Connection Heads: Aluminum, polypropylene, stainless steel
Explosion-Proof Options: FM/CSA Class I Div I, Groups B,C,D; Class II Div I, Groups E,F,G
Documents: Product Specs

Product Description

The Noshok 910/915 Series is an industrial probe-type RTD with temperature ranges from -330 to 1100°F. A variety of connection head types are available, including aluminum, polypropylene, and stainless steel. If the 910/915 RTD is used in conjunction with a thermowell, the probe can be replaced in some models without possibility for leakage.

Applications include industrial boilers, petrochemical, exhaust gas monitoring, and food processing.

Resources & Documentation

Noshok 910/915 Series RTD Datasheet PDF(315 KB)
