The Dwyer 626 / 628 Industrial Pressure Transmitter features corrosion resistant 316L stainless steel wetted parts that allow the Series 626 and 628 transmitters to measure the pressure in a multitude of processes from hydraulic oils to chemicals. The Series 626 and 628 are available in absolute and pressure ranges with a variety of optional outputs, process connections and electrical terminations to allow you to select the right transmitter for your application.

The Series 626 Pressure Transmitters possess a highly precise 0.25% full scale accuracy piezo-resistive sensor contained in a compact, rugged, NEMA 4X stainless steel general purpose housing or cast aluminum conduit housing.

The Dwyer Series 628 Pressure Transmitters are ideal for OEM's with 1% full scale accuracy sensors. The transmitter is also available in the general purpose stainless steel housing and the cast aluminum conduit housing.

Applications: Compressors, pumping systems, irrigation system pressure, fire pump control pressure, industrial process monitoring, refrigerant line pressures on air handlers when used with optional refrigerant valve depressor, trash compaction equipment.
