Product Specifications
- Brand
- Siemens
- Part Number
- 4AM4642-4TN00-0EB0
- Product Type
- Control Transformer
- Series
- SITAS 4AM4642
- Rated Power
- 400 VA
- Primary Voltage
- 230 V (taps: 218/230/242 V)
- Secondary Voltage
- 24 V
- Secondary Current
- 16.7 A
- Short-Time Power (S6)
- 1,440 VA
- Frequency
- 50/60 Hz
- Terminal Type
- Cage-Clamp
- Mounting
- DIN Rail
Product Description
The SITAS 4AM4642-4TN00-0EB0 is the DIN rail mount version of the 400VA 230V-to-24V control transformer, featuring cage-clamp spring-loaded terminals for tool-free, vibration-resistant wiring. Electrically identical to the 4TN00-0EA0 screw-mount variant.
Electrical Performance
Rated at 400VA continuous with a short-time power rating of 1,440VA (S6 duty). The EI 120/52 laminated core achieves approximately 91 percent efficiency. Primary taps at 218/230/242V accommodate mains voltage variation. Full galvanic isolation via II0 vector group.
Mechanical Design
Compact 122x121x114mm IP00 open-frame design. The 0EB0 variant differentiates with cage-clamp terminals and DIN rail mounting — reducing wiring time and enabling snap-on panel integration. Class B (130 C) insulation, rated for 40 C ambient.
Application
Suited for control panels where fast installation and maintenance are priorities. The DIN rail mount integrates directly into standard 35mm DIN rail enclosures, while cage-clamp terminals maintain reliable connections under vibration.
Decision Parameters
| Parameter | Value |
|---|---|
| Rated Power | 400 VA |
| Primary Voltage | 230 V (taps: 218/230/242 V) |
| Secondary Voltage | 24 V |
| Secondary Current | 16.7 A |
| Short-Time Power (S6) | 1,440 VA |
| Efficiency | ~91 percent |
| Insulation Class | B (130 C) |
| Protection Class | IP00 |
| Dimensions (WxHxD) | 122 x 121 x 114 mm |
| Mounting | DIN Rail |
