The Fuji Electric FSV-3 ultrasonic flow meter is the latest generation of high performance ultrasonic liquid flow meters using transit time technology . It is particularly effective in applications where high accuracy is required and the flow meter needs to be installed without shutting down the process. It is the perfect option for measuring flow rates of relatively clean, homogeneous liquids in closed, filled pipes .

The FSV-3 uses advanced digital signal processing technology to provide a compact, lightweight solution with accuracies that are better than ±1% of flow rate with minimal influence by the pressure or temperature of the measured fluid . It offers best-in-class anti-bubble performance, which allows for accurate readings with air bubble content as high as 12% volume at 3ft/s velocity .

The rugged construction makes it ideal for installation in internal and external environments where IP66 (NEMA 4X) protection is required and it is 2/3 the size of its predecessor. Configuration is simple and intuitive via push buttons on the front panel. Alternatively, free PC compatible software is available, allowing multiple configurations to be stored and downloaded from a PC to the meter with the optional loader cable. The FSV-3 requires clamp-on sensors that cover pipe diameters from 0.5 to 235 inches at liquid temperatures from -40 to 390°F .
