What sets the 5UB1101-0KK apart from the other screwless insert?

DELTA offers two screwless Schuko inserts — the 5UB1101-0KK (55 g) and the 5UB1101-5KK (46 g). The -5KK variant specifies a 2.5 mm² finely stranded conductor limit on the data sheet, while the -0KK is listed without a stated gauge ceiling. In practice both handle standard 1.5–2.5 mm² residential and light-commercial wiring without issue. The weight difference — 9 grams — and separate packaging dimensions suggest a terminal mechanism variation, though Siemens does not publicly document the exact internal difference. If your installation falls within standard 2.5 mm² wiring, the lighter -5KK saves a marginal amount of material; if you prefer the variant whose electrical specs track the broader DELTA portfolio, the -0KK is the reference screwless option.

Which installations benefit most from screwless terminals?

Push-in screwless terminals cut installation time roughly in half versus screw-down clamping — strip the conductor to 11 mm and push it straight into the terminal. This makes the 5UB1101 series the faster choice for multi-unit residential or office projects where dozens of sockets are installed in a single day. The trade-off: screwless terminals typically accept a narrower conductor gauge range than screw types. For 4 mm² or mixed-gauge wiring, use the screw-terminal 5UB1100-5KK instead.
