Product Specifications
Brand: Fluke
Model Number: 700G
Type: Digital Pressure Gauge
Pressure Range: 15 to 10,000 psi (absolute to 300 psia)
Accuracy: 0.05% FS, reference class 0.04% reading
Safety Rating: CSA Class 1 Div 2, ATEX
Documents: Product Manual, Product Specs
Product Description
The Fluke 700G Pressure Gauge is portable, high-quality calibrator for fast and accurate calibration test results. It can be combined with the 700PTPK or 700HTPK pump kits for a complete pressure testing solution for up to 600 psi with the PTP-1 pneumatic pump and up to 10,000 psi with the HTP-2 hydraulic pump. Look for them in the accessories list.
The Fluke-700PTPK Pneumatic Test Kit features include: Combine with Fluke-700G Series Gauge, 1,000 psi or less; Generate pressure up to 600 psi, 40 bar with the 700PTP-1 test pump; Connect the 700G Series gauge directly to the included PTP-1 hand pump; Includes hoses and adapters for connecting to the pressure device to be tested; Hard case protects pump and gauge and allows gauge to remain connected to the pump.
The Fluke-700HTPK Hydraulic Test Kit: Combine with Fluke-700G Series Gauge, 1,000 psi range or greater; Generate pressure up to 10,000 psi, 690 bar with the included 700HTP-2 test pump; Connect the 700G Series gauge directly to the HTP-2 hand pump; Includes 700HTH-1 hose kit and adapters for connecting to the pressure device to be tested; Hard case protects pump and gauge and allows gauge to remain connected to the pump.
Portable Pressure Gauge - Test Kit Compatible | Fluke 700G
Product Specifications
Brand: Fluke
Model Number: 700G
Type: Digital Pressure Gauge
Pressure Range: 15 to 10,000 psi (absolute to 300 psia)
Accuracy: 0.05% FS, reference class 0.04% reading
Safety Rating: CSA Class 1 Div 2, ATEX
Documents: Product Manual, Product Specs
