The Siemens 5UB1847 is a white Schuko socket outlet from the DELTA style series, combining a spring-loaded hinged cover, an integrated label window, and increased touch protection. The neutral white finish blends with standard wall plates in residential and commercial settings, while the transparent title block lets electricians insert a circuit ID strip for traceable installations.

Label Window + Touch Protection — Why Both?

In commercial buildings and public facilities, two requirements often coincide: every socket must be circuit-labeled for maintenance traceability, and every socket must meet increased touch protection standards (VDE 0620). The 5UB1847 addresses both in one device. The label window is built into the hinged cover itself — slide in a printed strip and the circuit ID is visible whether the cover is open or closed.

Installation Notes

The 5UB1847 uses plug-in terminals for fast wiring and mounts into standard flush-mount back boxes via claw and/or screw fixing. It accepts all CEE 7/4 (Schuko) plugs. Halogen-free thermoplastic housing, RoHS compliant, VDE 620 certified.
