The 8UB9530 is a simple but essential finishing touch for any control cabinet equipped with 8UC rotary operating mechanisms. This blank masking plate snaps into the standard 96×96 mm panel cutout, covering the unused opening and giving the door a clean, professional appearance. It carries no electrical function — its job is purely mechanical and aesthetic.

Compatibility

• Designed specifically for 8UC series operating mechanisms from the SENTRON range.
• Fits standard 96×96 mm cutouts commonly used in switchgear and motor control centre doors.
• Works alongside door-coupling rotary handles, shaft extensions and other 8UC accessories.

Physical Specifications

• Outer dimensions: 96 mm × 96 mm, matching the 8UC footprint.
• Weight: approx. 20 g — a lightweight plastic frame that adds negligible load to the door.
• Material: industrial-grade thermoplastic, colour light grey (similar to RAL 7035).
• Protection rating contribution: helps maintain IP2X on the cabinet front when correctly fitted.

Installation & Ordering

• Mounts directly in the front panel cutout without tools; the plate clips or screws into place depending on the panel design.
• Supplied as a single piece, GTIN/EAN 4011209076976.
• Country of origin: Germany.
• Customs tariff code: 85389099.
