The 6SL3260-2DB00-0AA0 is the complete replacement plug kit for SINAMICS S210 servo drives with 1 AC mains connection. It includes every plug-in connector on the drive — from power terminals to signal connections.

What connectors are included?

Five connectors plus shield plate: X1 mains + external braking resistor (integrated, with jumper for internal brake resistor), X2 motor connection, X107 motor holding brake, X124 24 V DC external supply, and X130 digital inputs. Power connectors (X1/X2) are Weidmüller BLF 5.08HC rated 0.2–2.5 mm². Shield plate fits FSA, FSB, and FSC frames.

1 AC or 3 AC — which kit?

This kit (2DB00) is for 1 AC S210 drives. Power terminals accept up to 2.5 mm² wire. For 3 AC 400 V drives, order 6SL3260-2DB10-0AA0 — same signal connectors but larger 6 mm² power terminals and a separate X4 braking resistor connector.
