PI A-811.CE 1-Axis PIglide Controller with STO, 5 A Drive

1 / 5

Product Specifications

Brand: Physik Instrumente (PI) GmbH & Co. KG
Part Number: A-811.CE
Type: 1-Axis Motion Controller with Servo Drive
Axes: 1
Motor Types: Voice coil, brushed DC, brushless 3-phase
Output Current: 5 A continuous, 10 A peak
Encoder: Incremental 1 Vpp, BiSS-C, EnDat 2.2
Safety: STO, SS1
Communication: Ethernet TCP/IP, EtherNet/IP

Product Description

The A-811.CE is PI's single-axis controller for PIglide air-bearing stages, packing the controller and servo drive into one benchtop unit built on the ACS ECMsa motion engine.

Why pair a dedicated controller with an air-bearing stage?

An air-bearing stage rides on a film of air, so any cogging or ripple in the drive shows up directly as motion error. The A-811.CE drives voice-coil, brushless or DC motors with a quiet PWM output and reads high-resolution encoders, so the stage's own precision — not the drive — becomes the limit.

5 A continuous, 10 A peak output
Incremental, BiSS-C and EnDat 2.2 encoder inputs
STO and SS1 functional safety
Ethernet TCP/IP and EtherNet/IP

Against a generic servo drive, the A-811.CE arrives pre-tuned for PI stages, so the air-bearing axis is commissioned in one sitting rather than a week of servo tuning.
