The 6ES7952-1AP00 is an 8 MB RAM memory card for SIMATIC S7-400 controllers. Unlike FEPROM cards, RAM cards merge with the CPU's built-in load memory to form one contiguous storage area — the CPU sees a single, unified load memory pool rather than two separate volumes. This architecture enables the defining advantage of RAM: you can download program changes while the CPU is in RUN mode, without stopping the process. The card requires a backup battery (or external backup voltage via the CPU's EXT.BATT socket) to retain data through a power cycle.

Why choose RAM over FEPROM for your S7-400?

Three reasons, all centered on uptime. First, RUN-mode downloads — modify code blocks and download them without transitioning the CPU to STOP. This is essential for continuous processes, batch reactors, and production lines that cannot be interrupted. Second, CFC online monitoring — RAM cards support viewing CFC chart status, interlocks, and signal flow in real time, a capability that FEPROM cards do not offer. Third, PCS7 compatibility — Siemens officially recommends RAM cards for PCS7 process control projects, where online changes and CFC monitoring are part of the standard engineering workflow. The cost of these capabilities is the backup battery, which must be maintained and replaced periodically.

What does 8 MB of RAM load memory get you?

8 MB of unified RAM load memory accommodates a well-structured S7-400 program with function blocks, data structures, and CFC charts for a typical PCS7 process control application of moderate size. The RAM card's capacity adds to the CPU's internal load memory — if your CPU has 4 MB of internal RAM load memory, adding this 8 MB card gives you a total of 12 MB of contiguous load memory. Check your STEP 7 or PCS7 project size to confirm the total load memory requirement before ordering.

Frequently Asked Questions

What happens if the backup battery fails?

If both the internal CPU battery and any external backup voltage fail while the system is powered off, the data on the RAM card is lost. The CPU will indicate a memory fault on the next power-up and will request a complete program download. This is why battery monitoring and scheduled replacement are essential when using RAM cards — Siemens recommends replacing the backup battery every 1–2 years as preventive maintenance.

Can I mix a RAM card with a FEPROM card in the same S7-400?

No. The S7-400 has a single memory card slot. You choose either a RAM card or a FEPROM card — one card serves as the entire external load memory. You cannot install both simultaneously.
