The Easy Pal 625-1900F is a 6-axis collaborative robot purpose-built for end-of-line palletizing, automatically stacking boxes, bundles, and packaged goods onto standard pallets while operating safely alongside human workers. With a 25 kg payload and 1,900 mm reach, it targets medium-throughput packaging lines where flexibility and compact footprint are as critical as stacking speed.

What payload capacity and operating reach does the Easy Pal 625-1900F provide?

The 625-1900F handles payloads up to 25 kg across a 1,900 mm operating radius. It achieves a cycle rate of up to 6 boxes per minute at a maximum working speed of 1.2 m/s, accommodating box dimensions from 260 × 200 × 150 mm up to 500 × 450 × 400 mm on pallets up to 1,200 × 1,200 mm. The maximum palletizing height reaches 2,100 mm including the pallet.

How does the 625-1900F differ from other Easy Pal variants?

The 625-1900F is differentiated by its 1,900 mm reach — the longest in the Easy Pal series. Sibling models such as the Easy Pal 620-1650F and Easy Pal 635-1650F offer a 1,650 mm reach, making the 625-1900F the choice for production lines requiring extended arm coverage to service larger pallet footprints or multiple pick-and-place stations from a single fixed mounting position.

What integration and safety features does it include?

The cobot supports EtherCAT, ModbusTCP, and TCP/IP communication for integration with upstream packaging equipment and plant-level control systems. The robot arm carries an IP54 protection rating, with the end effector rated at IP32. Collaborative safety is achieved through native power-and-force-limiting design, supplemented by an emergency stop circuit, an external safety I/O interface, and optional LiDAR or safety fencing for applications that require zoned speed reduction or monitored standstill.
