The 5UB1518-0KA is the kit-packaged version of the DELTA i-system increased-touch-protection SCHUKO socket. The -0KA suffix indicates kit packaging: the box contains the 5UB1518 socket insert (55 × 55 mm, titanium white, VDE 0620 increased touch protection, screwless terminals, 16A/250V) plus a matching titanium white single-gang frame. One PN, one box, ready to fit into the flush box.

Insert-only vs. kit: which one do you need?

The base PN 5UB1518 is the socket insert only — the active electrical component with terminals, contacts, and the 55 × 55 mm cover plate. It requires a separate DELTA i-system frame (single, double, or multi-gang) to complete the installation. The 5UB1518-0KA kit eliminates the second SKU: the insert and a matching single-gang titanium white frame ship together. For a new installation where you would be ordering both anyway, the kit saves an order line and guarantees color matching. For replacements — where the existing frame is already on the wall and only the insert needs swapping — order the base 5UB1518 insert instead.

What if I need a multi-gang configuration?

The kit includes a single-gang frame only. If the installation calls for two or more sockets in a shared multi-gang frame, order the required number of 5UB1518 inserts plus a separate multi-gang DELTA i-system frame in titanium white — the kit's included single frame would be unused. Multi-gang frames are ordered under the DELTA i-system frame PN range (e.g., 5TG series).

Frequently Asked Questions

Does the kit frame match other DELTA i-system soft black or colored frames?

The 5UB1518-0KA includes a titanium white frame only. If you need the soft black version, order 5UB1518-0SB01 (soft black insert) plus a separate soft black single frame. There is no soft black kit variant of the 5UB1518.

Is the kit available with clawless mounting?

No — the kit suffix (-0KA) and clawless suffix (-0KK) are mutually exclusive. If you need increased touch protection with clawless mounting, order the 5UB1518-0KK insert plus a separate frame.
