Product Specifications
- Manufacturer
- Core Sensors
- Model Number
- CS84
- Product Type
- Intrinsically Safe Differential Pressure Transducer
- Differential Pressure
- Up to 50 psi
- Accuracy
- ≤ ±0.25% BFSL (≤ ±0.5% BFSL for 2 psi and below)
- Line Pressure
- 500 psi max
- Enclosure Rating
- IP65
- Documents
- Product Manual, Product Specs
Product Description
The CS84 intrinsically safe differential pressure transducer features an all-welded stainless steel construction for a minimum IP65 rating. A 316L SS oil-filled sensor element provides excellent stability over a wide operating temperature range, while offering corrosion resistance against various liquids and gases. The CS84 features differential pressure ranges up to 50 psi, optional bi-directional ranges, 1/4-inch MNPT and FNPT process connections and a wide range of configurable options for operation in harsh conditions.
Applications include filtration and external tank level measurement.
Intrinsically Safe Differential Pressure Transducer - 50 PSI | Core Sensors CS84
