DELTA Cat 3 universal junction box — single port, angled outlet. The inclined RJ jack aims the plug downward at roughly 45 degrees, so the cable runs flat against the wall instead of jutting straight out into the room. A small detail that matters when the socket is at desk height or in a corridor where a protruding plug gets snagged.

Angled vs. straight outlet: when does it matter?

The angled outlet solves two practical problems. First, in narrow corridors or behind furniture, a straight RJ45 plug can extend 35–40mm from the wall — enough to conflict with a desk pushed against it or to catch a passing shoulder. The angled outlet reduces that protrusion to near-zero by redirecting the cable along the wall plane. Second, the downward angle creates a natural drip loop, reducing the chance that a spilled drink on a desk above the socket runs down the cable into the jack.

1-port vs. 2-port (5TG2406): how to decide?

If the location needs only a single telecom drop — a fax machine, a single ISDN terminal, an elevator phone — the 1-port insert is all you need. A 1-port insert also leaves the second slot in a dual module carrier free for a non-telecom function. If the location needs two separate lines (phone + DSL, or two independent phone lines), use the 2-port 5TG2406. Two single-port inserts cost more and consume both module-carrier slots.

Cat 3 limitations

16MHz bandwidth, suitable for analog telephony, ISDN (BRI/PRI), ADSL/VDSL, and 10BASE-T Ethernet only. Not for 100BASE-TX or faster. If you are pulling new cable to this location, install Cat 6E or Cat 6A junction boxes instead — Cat 3 is for matching existing Cat 3 infrastructure.
