The 6SL3520-1XH61-1AF0 is the PROFINET variant at the 1.1 kW step in the G115D FSA range. Under the 1XH61 sub-code, it delivers 6.2 A with PROFIdrive communication and fanless cooling — a drive that is small enough to power a single belt section but fully visible on the TIA Portal network.

PROFINET at 1.1 kW — the network reaches every drive

1.1 kW conveyor sections — feeder belts, small roller beds, reject gates — are traditionally the least monitored drives on a line. They are small enough that hardwired I/O has been the default, and their failure mode is typically discovered when the upstream section's photo-eye detects a product jam. The AF0 PROFINET interface changes that: this drive reports speed, current, and fault status to the PLC in real time over PROFIdrive. If motor current rises due to a stiff bearing on the driven roller, the SCADA historian sees the trend. If the drive trips on overcurrent, the SCADA identifies exactly which drive — not just which conveyor zone.

1XH61 AF0 — the networked 1.1 kW

The 1XH61 sub-code identifies this hardware revision. Like all FSA variants, it is fanless — natural convection only, ~250 mA at 24 V DC, 380 mm housing width. The PROFINET interface adds an RJ45 port and full TIA Portal integration without changing the drive's thermal or mechanical characteristics.
