The SITAS 4AM6442-5AT10-0FA1 is the cage-clamp variant of the flagship 2000VA 400V-to-230V control transformer. Identical in electrical performance to the -0FA0 but with spring-loaded cage-clamp terminals for tool-free, vibration-resistant wiring — ideal for panel builders prioritizing fast assembly and maintenance-free connections.

Electrical Performance

Rated at 2,000VA continuous with a short-time power rating of 9,700VA (S6 duty) — nearly 5x headroom. The EI 174/102 laminated core achieves approximately 96 percent efficiency. Primary taps at 380/400/420V. Full galvanic isolation via II0 vector group.

Mechanical Design

Substantial 158x176x164mm IP00 open-frame construction. Cage-clamp spring-loaded terminals for vibration-resistant, maintenance-free connections and faster panel assembly than conventional screw terminals. Screw-mount chassis. Class B (130 C) insulation, rated for 40 C ambient. Weighs approximately 25 kg.

Application

Same flagship 2000VA European control panel application as the -0FA0, preferred where panel builders want tool-free wiring and vibration-proof connections for the largest multi-contactor and multi-drive automation systems.
