Siemens 3NJ6930-3DC00 CT Busbar, 3 Transformer Positions, NH1

1 / 5

Product Specifications

Brand: Siemens
Part Number: 3NJ6930-3DC00
Product Type: Current Transformer Busbar
Series: SENTRON 3NJ693
Suitable For: Switch disconnector with fuses, in-line design, NH1
Number of CT Positions: 3
Rated Operational Voltage: 690 V AC / 440 V DC
Standard: IEC EN 60947-3
Net Weight: 0.366 kg

Product Description

The 3NJ6930-3DC00 is a CT busbar assembly for mounting three bushing current transformers onto a SENTRON 3NJ6 (NH1) in-line switch disconnector with fuses. Designed for the larger NH1 frame size with three CT positions for complete three-phase monitoring on higher-current feeders.

NH1 Frame — Higher Current Capacity

The NH1 frame supports larger fuse links and higher continuous currents than NH00. This three-position busbar assembly enables full three-phase current measurement on NH1-rated feeders, with each position accepting a standard bushing-type CT.

Key Parameters

Parameter	Value
Suitable For	3NJ6 switch disconnector, NH1
CT Positions	3
Rated Operational Voltage	690 V AC / 440 V DC
Standard	IEC EN 60947-3
Net Weight	0.366 kg

Retrofittable Design

All 3NJ6930 series busbar assemblies can be retrofitted at any time — no need to disconnect the main circuit or remove the switch disconnector from the panel. The plug-in interface ensures quick installation without tools, letting panel builders add metering capability as requirements evolve.
