The FITOK FSR-16L-45-100 is a 6-port pressure calibration control panel built from 316L stainless steel for high-integrity gas handling. It combines an RDGC series pressure regulator with inlet and outlet pressure gauges, a proportional relief valve, and a bleed valve for safe system depressurisation. The panel is cleaned and packaged for oxygen service, making it suitable for calibration gas mixtures in analytical and process instrumentation.

Why does helium leak testing matter for calibration panels?

Each FSR panel is helium leak-tested to an internal leak rate below 1 x 10^-7 standard cubic centimetres per second and an external rate below 1 x 10^-5 std cm3/s. In calibration applications, even microscopic leakage can shift gas mixture concentrations over time, invalidating calibration certificates and causing measurement drift in downstream analysers. The all-welded 316L construction with PCTFE seats and Hastelloy diaphragms ensures the calibration gas reaching the instrument is identical to what left the cylinder.

How does the panel support safe cylinder changeover?

The integrated bleed valve allows controlled venting of residual pressure before disconnecting gas cylinders, protecting technicians from sudden gas release. The inlet port plug provides secondary containment during transport and storage. An outlet proportional relief valve protects downstream instrumentation from overpressure if the regulator experiences creep or thermal expansion of trapped gas volumes.
