Product Specifications
Manufacturer: QUADRIOS
Part Number: 22C447
Product Type: Insulated Ring Cable Lug
Package Quantity: 100 pieces
Cable Cross-section: 1.5-2.5 mm²
Hole Diameter: 5.3 mm (M5)
Color: Blue
Contact Material: Tin-plated copper
Insulation Material: PVC
Max. Voltage: 600 V
Max. Current: 27 A
Product Description
The QUADRIOS 22C447 is an insulated ring cable lug for 1.5-2.5 mm² stranded wires, sized for M5 studs. The blue insulation follows DIN color coding for this wire gauge range.
The tin-plated copper barrel provides a gas-tight crimp and low contact resistance. The PVC insulation protects against shorts and indicates the terminal size. Use a ratcheting crimping tool for insulated ring terminals.
Each bag contains 100 pieces. Common applications include power supply connections, relay outputs, and industrial control panel wiring.
