The Time Electronics 1068 fixed resistance box is a compact, highly accurate instrument with five fixed resistance values designed for industrial, general laboratory, and education requirements. Housed in a robust case, the 1068 is easily portable and takes up minimal bench space.

The high accuracy is achieved through the use of precision resistors. To select a value, simply connect test leads to one of the fixed value resistors: 1Ω, 10Ω, 100Ω, 1kΩ, or 10kΩ. Connection is via 4mm binding posts with values clearly indicated beside each terminal.

Being a low cost and simple operation instrument, it is a popular model for physics and electronics laboratories in universities and schools.

Key Features

• Five fixed resistance ranges: 1Ω, 10Ω, 100Ω, 1kΩ, 10kΩ
• High accuracy: 1Ω range ±1mΩ, 10Ω range ±5mΩ, 100Ω range ±10mΩ, 1kΩ range ±100mΩ, 10kΩ range ±1Ω
• Clear visual indication of values
• Portable and compact design
• Simple operation
• Robust casing
• 4mm binding post connectors

Applications

• Physics and electronics education
• General laboratory work
• Industrial testing
• Calibration reference
