Product Specifications

Product Description

The RAE Systems MiniRAE 3000 is an advanced handheld volatile organic compound (VOC) monitor featuring a photoionization detector (PID) with an extended range of 0 to 15,000 ppm. It is designed for industrial hygiene, leak detection, and HazMat applications. The instrument provides accurate measurements with the fastest response time in its class at just 3 seconds.

A strong, built-in sample pump draws up to 100 feet horizontally or vertically, enabling remote sampling. The rugged, IP67-rated housing allows for easy cleaning and decontamination, and the integrated flashlight improves visibility in low-light conditions. The MiniRAE 3000 supports multiple languages, offers 6 months of data logging at 1-minute intervals, and features bright visual and 95 dB audible alarms. It is intrinsically safe with CSA and ATEX certifications, and includes a 3-year lamp warranty.

RAE Systems

VOC Monitor - PID 0-15000ppm | RAE Systems MiniRAE 3000

3s response, IP67, 100ft pump
MPN/Series: MiniRAE 3000

Product Specifications

Manufacturer : RAE Systems

Model Number : MiniRAE 3000 (PGM-7320)

Type : Gas Detectors

Measurement Range : 0 to 15,000 ppm (VOCs)

Response Time : 3 seconds

Pump Flow Rate : 500 cc/min, draws up to 100ft

Enclosure Rating : IP67

Wireless : BLE up to 15 ft (5m)

Documents: Product Manual, Product Specs
