6EP1322-5BA10 SITOP PSU100C 12V DC 6.5A 78W, Siemens

1 / 5

Product Specifications

Brand: Siemens
Part Number: 6EP1322-5BA10
Type: Stabilized Power Supply
Series: SITOP PSU100C
Input Voltage: 120–230 V AC
Output Voltage: 12 V DC
Output Current: 6.5 A
Output Power: 78 W

Product Description

The Siemens 6EP1322-5BA10 is one of the few SITOP power supplies delivering a regulated 12 V DC rather than the standard 24 V, rated at 6.5 A for applications such as LED lighting controllers, legacy 12 V automation equipment, and specialized sensor arrays powered from a 120–230 V AC mains supply.

Why 12 V Instead of 24 V

Directly powers 12 V DC motors, LED strips, camera systems, and communication gear without step-down converters
120–230 V AC auto-range input covers global single-phase supplies
Compact PSU100C form factor at 0.32 kg for DIN rail installation
Short-circuit protection with electronic shutdown and automatic restart

Technical Specifications

Parameter	Value
Input Voltage (AC)	120–230 V (also 110–300 V DC)
Output Voltage	12 V DC
Output Current	6.5 A rated
Output Power	78 W
Protection Class	IP20
Mounting	DIN Rail
Weight	0.32 kg
Certifications	CE, UKCA, cULus, EAC
Origin	Romania

Series Context

The PSU100C is Siemens' entry-level SITOP series. For the same 12 V output in the higher-performance PSU6200 range with diagnostic interface, consider the LOGO!Power 12 V variants. For standard 24 V needs, the 6EP1332-2BA20 PSU100S provides 24 V / 2.5 A in a similar form factor.
