Product Specifications
- Brand
- Siemens
- Part Number
- 6SL3230-3YE50-0AB0
- Type
- General-Purpose Frequency Converter
- Series
- SINAMICS G120X
- Rated Power
- 160 kW
- Supply Voltage
- 3AC 380-480 V
- Output Current
- 408 A
- Frame Size
- FSG
- EMC Class
- C2, built-in filter
- Paint Finish
- 3C3
- Degree of Protection
- IP20 / UL open type
- Communication
- Modbus RTU, BACnet MS/TP, USS
Product Description
The 6SL3230-3YE50-0AB0 is a SINAMICS G120X drive rated 160 kW at 380 to 480 V three-phase input, with a 408 A output current, frame size FSG, and an IP20 open-type enclosure that measures 305 mm wide, 369 mm deep and 999 mm high at 125.5 kg. Overload capacity is 110 percent for 60 seconds and 100 percent for 240 seconds.
A category C2 radio interference filter is built in, which covers the standard industrial environment without an external choke. The paint finish is 3C3, the higher coating class for sulphur and humidity, and the drive can sit in works with corrosive air. Ambient temperature runs from -20 to +45 degrees Celsius.
Modbus RTU, BACnet MS/TP and USS run over the on-board RS485 port, and no fieldbus option card is needed for those protocols. No operator panel or I/O module is included. Commissioning uses the IOP-2 handheld or the Startdrive tool over USB.
The drive is an indoor cabinet component, not a decentralized unit, and it carries no integrated disconnect, no line reactor and no brake chopper. A C3 filter, a 3C2 coating or a built-in panel is covered by a different ordering code in the same G120X family.
Motor cable length and pulse frequency derating follow the G120X operating instructions, not a fixed site rule. Overtemperature protection expects a motor thermistor or PTC input wired to the drive terminals.
