SITOP PSU8200 6EP3337-8SC00-0AY0 24VDC 40A 960W Industrial Power Supply

1 / 5

Product Specifications

Brand: Siemens
Part Number: 6EP3337-8SC00-0AY0
Series: SITOP PSU8200
Type: Stabilized Power Supply
Packaging: Industrial Multi-Pack
Input Voltage: 120/230 V AC (85–132/170–264 V AC)
Output Voltage: 24 V DC (adjustable 24–28 V)
Rated Current: 40 A
Rated Power: 960 W

Product Description

The bulk-packaged variant of the PSU8200 40A series, the 6EP3337-8SC00-0AY0 offers the same electrical performance as the standard-pack version in an industrial multi-pack format optimized for panel builders and OEM volume production.

Same Electrical Platform, Volume Packaging

Electrically identical to the standard 8SB00 variant: 24V DC output at 40A continuous, 150% extra power for 5s/min, and selectable constant-current or latching shutdown. The 85–264V AC auto-ranging input covers single-phase mains worldwide.

Built for Control Cabinet Standardization

When standardizing on a single high-power 24V PSU across multiple machine builds, the industrial multi-pack simplifies procurement and inventory. Each unit retains the full relay signaling, LED status indication, and parallel-operation capability of the standard variant.

Parameter	Value
Input Voltage Range	85–132 V AC / 170–264 V AC
Rated Output Voltage	24 V DC (adjustable 24–28 V)
Rated Current	40 A
Rated Power	960 W
Efficiency	92%
Overload Capability	150% for 5 s/min
Dimensions (W×H×D)	145 × 145 × 150 mm
