Product Specifications

Brand: Siemens

Part Number: 6AG1332-6SB00-7AY0

Type: Stabilized Power Supply (Ruggedized)

Series: SIPLUS LOGO!Power

Input Voltage: 100–240 V AC

Output Voltage: 24 V DC

Output Current: 2.5 A

Operating Temperature: -40 to +70 °C

Product Description

The Siemens 6AG1332-6SB00-7AY0 is the SIPLUS ruggedized variant of the LOGO!Power 24 V / 2.5 A power supply, engineered with conformal coating protection and an extended -40 to +70 °C operating range for deployment in outdoor cabinets, cold storage, and corrosive industrial atmospheres where standard power supplies would fail.

What SIPLUS Brings

Conformal coating on PCBA protects against condensation, dust, and chemical vapors
-40 °C cold-start capability — powers up reliably in unheated outdoor enclosures and freezer applications
Based on the proven LOGO!Power 6EP3332-6SB00-0AY0 design with identical 24 V / 2.5 A output
Made in Germany with extended factory lead time (65 days) reflecting the additional manufacturing steps

Technical Specifications

Parameter	Value
Input Voltage	100–240 V AC
Output Voltage	24 V DC
Output Current	2.5 A
Output Power	60 W
Operating Temperature	-40 to +70 °C (start-up -25 °C)
Protection Class	IP20
Conformal Coating	Yes
Weight	0.21 kg
Certifications	CE, RoHS

Typical Deployments

Specified for wind turbine nacelle controls, outdoor pumping stations, refrigerated warehouse conveyors, and chemical plant auxiliary panels where temperature extremes, humidity, or airborne contaminants rule out standard commercial power supplies.
