Product Specifications
- Brand
- Siemens
- Series
- SINAMICS G115D
- Product Type
- Distributed Drive (Wall-Mounted)
- Rated Power
- 1.1 kW
- Supply Voltage
- 3AC 380-480 V
- Rated Current
- 6.2 A
- Output Frequency
- 0-550 Hz
- Frame Size
- FSA
- Degree of Protection
- IP65/IP66, UL Type 4X
- Communication
- PROFINET, EtherNet/IP
- Safety Function
- STO SIL 2 / PL d via F-DI
- Overload Capability
- 200% / 3 s, 150% / 57 s
- Cooling
- Natural Convection (fanless)
Product Description
When the section must drop into an existing PROFINET line with wired safety
The 6SL3520-2XC01-1AB0 is the standard PROFINET variant for conveyor zones already covered by a hardwired STO loop - it communicates over PROFINET like every other 2XC unit while STO runs on the F-DI terminal.
Is the AB0 different from the AA0 in this power?
Both are standard PROFINET without PROFIsafe; they are distinct order codes within the 1.1 kW class. Performance is identical at 6.2 A - pick the one your regional stock or wiring option calls for.
