The 6SL3520-1XM01-1AF0 is the 1.1 kW, FSA-frame G115D in the 1XM variant with AF-suffix PROFINET communication — the fieldbus-equipped entry point for decentralized automation in SIMATIC environments. Rated 3.1 A continuous (6.2 A peak at 200% for 3 seconds), it powers light-duty conveyor sections, diverters, and roller beds directly on the machine frame. The 1XM FSA enclosure (380 × 216 × 129 mm) provides IP65/IP66 protection with natural-convection cooling.

The AF suffix integrates dual-port PROFINET and EtherNet/IP — the drive appears as a node on the automation network with full telemetry, diagnostics, and parameter access via TIA Portal. This eliminates the discrete I/O wiring and gateway modules that a base-variant (AA) or enhanced-I/O (AB) drive would require for networked control at the 1.1 kW level. Standard G115D features: integrated C2 EMC filter, internal braking chopper, STO SIL 2 via Profisafe, SAM web-server commissioning, and IP65/IP66 protection for washdown and dusty environments.
