The Ametek Type T hydraulic deadweight tester offers laboratory accuracy in an instrument designed to withstand industrial environments and daily manufacturing stresses. Available in ranges to 15,000 psi, this robust primary pressure standard maintains outstanding accuracy and repeatability even with repeated daily use .

The Type T features a re-entrant piston/cylinder assembly that applies test fluid to both outside and inside of the cylinder. This design reduces clearance as pressure increases, decreasing fluid leakage and increasing float time for more relaxed testing. Overhung weight carriers lower the center of gravity of the weight stack, reducing side thrust and friction to extend piston/cylinder life and improve measurement accuracy .

A dual-volume pumping feature allows rapid filling at low pressures, then switches to smaller volume for fine control at higher ranges. The reservoir remains at atmospheric pressure, enabling refilling during a calibration run. Available with single column for field use or dual column for laboratory applications, with accuracies of ±0.100%, ±0.025%, and ±0.015% of reading. Construction uses 300 series stainless steel and Monel for compatibility with various hydraulic fluids or water/alcohol mixtures .

Key Features

• Pressure range: 10 to 15,000 psi (0.7 to 1000 bar)
• Accuracy options: ±0.015%, ±0.025%, ±0.100% of reading
• Repeatability: ±0.005% of indicated reading
• Re-entrant piston/cylinder design for increased float time
• Overhung weight carriers reduce friction and improve accuracy
• Dual-volume pump for rapid filling and fine pressure control
• Available in single column (field) or dual column (lab) configurations
• Available pressure units: psi, kg/cm², bar, kPa
• Over-pressure protection prevents piston damage
• Small incremental weight sets available for fractional output pressures

Applications

• Laboratory calibration of pressure transmitters, transducers, and gauges
• Industrial manufacturing environment testing
• Production testing and quality assurance
• Field calibration with single column configuration
