Product Specifications

Product Description

The Jewell Instruments Model C820 Series Tiltmeter is a high precision submersible tiltmeter for use in fresh and salt water applications with 4-20mA output. Using an absolute gravity referenced electrolytic sensor, the C820 delivers superior measurement accuracy with virtually no longterm drift. High-gain units are sensitive to less than 0.0017 mm/m or better. All units are rated to 200 meters waterproof for advanced protection from the elements. Use the C820 "Shallow Water" for structural monitoring, angle measurement and control, platform leveling, and more.

Jewell Instruments

Submersible 4-20mA Tiltmeter - Shallow Water | Jewell C820

4-20mA output, ±0.5°/±3°/±50° ranges, 316 SS, 200m depth
MPN/Series: C820

Product Specifications

Manufacturer
Jewell Instruments
Model Number
C820
Type
Submersible Tiltmeter
Ranges
±0.5°, ±3°, ±50°
Resolution
<0.0001°, 0.0006°, 0.01°
Output
4-20 mA (2-wire current loop, per axis)
Protection
316 SS housing, 200m depth rating
Documents
Product Specs
