The Autonics TX series represents a significant advancement in temperature control interface design. By utilizing a large LCD display with white PV characters, it provides superior visibility from various angles and lighting conditions compared to traditional LED displays.

Key Features

• Space-Saving Design: The body depth has been reduced to just 45mm, making it approximately 30% shorter than previous models, ideal for installation in shallow control panels.
• Precision Control: A 50ms high-speed sampling cycle ensures accurate regulation for processes requiring rapid thermal response.
• Integrated Communication: Built-in RS-485 interface allows for seamless integration into SCADA systems or remote monitoring via PLC using Modbus RTU protocol.
• Flexible Output Control: Users can switch between relay output and SSR drive output, providing compatibility with various power control devices.

Technical Specifications

• Power Supply: 100-240VAC 50/60Hz
• Input Types: Multi-input (Thermocouple: K, J, T, R, S, L; RTD: Pt100, Cu50)
• Protection: IP65 front panel protection (IEC standard)

Applications

• Food processing and packaging machinery
• Plastic injection molding and extrusion
• Semiconductor manufacturing equipment
• HVAC and industrial furnace monitoring
