The Armstrong International FHC Series Electric Condensate Pump is designed for pumping water at temperatures up to 200°F. It includes a standard cast iron receiver, is floor-mounted, and engineered for up to 20,000sq ft EDR with discharge pressures up to 20psig. Units are available in either simplex or duplex configurations with 3500 RPM, single-phase motors. Pumps are typically equipped with industry-standard motors and mechanical seals rated for temperatures up to 250°F.

Features

• 20psi maximum discharge pressure
• 12 or 22.5gpm pump capacity
• 15 or 24gal receiver capacity
• Motor specifications:
  • 1/60/115-230V
  • ODP enclosure
  • 3500 RPM
  • 1/2 HP (all duplex options, and simplex with 22.5gpm capacity)
  • 1/3 HP (simplex with 12gpm capacity only)
• Included components:
  • NEMA 1 float switch (simplex only)
  • NEMA 1 mechanical alternator (duplex only)
• Floor-mounted design
• Mechanical seals rated up to 250°F
