The 6SL3230-3YE44-1AB0 is the most comprehensively equipped 90 kW variant in the G120X FSF-frame range. The B-suffix designates the full-feature configuration: an integrated Category C2 EMC filter for conducted emission compliance, DC terminals for motor-side du/dt or sine-wave filter connection, and the complete G120X communication and I/O suite. An engineer specifying this variant gets factory EMC compliance and full motor protection flexibility without the procurement lead time of external components.

Rated for 241 A output at 480 V three-phase with 110% overload for 60 seconds, the drive runs MODBUS RTU, BACnet MS/TP, and USS concurrently. The 6 DI / 2 AI / 1 AO complement covers speed reference, sequencing, and feedback, while the RS-232 port handles point-to-point diagnostics. The IP20 FSF enclosure measures 305 × 709 × 360 mm and is designed for standard control cabinet integration.
