The 6SL3230-3YE46-0AB0 delivers 110 kW of quadratic-load output in the FSF frame size of the SINAMICS G120X series, rated for 210 A at 480 V three-phase. The integrated Category C2 EMC filter satisfies EN 61800-3 conducted emission limits for industrial environments without an external filter module, reducing cabinet footprint and installation complexity compared to unfiltered drive variants. The 0AB0 suffix designates a standard-configuration unit with factory-installed C2 radio interference suppression, sized for large centrifugal pump, axial fan, and compressor applications with 110% overload for 60 seconds and 100% for 240 seconds.

How does this variant differ from other FSF-frame G120X models?

At 110 kW and 210 A, this unit sits above the 90 kW FSF variants in output power while sharing the same 305 × 709 × 360 mm (W×H×D) footprint and 84 kg weight. The integrated C2 filter eliminates the need for an external EMC filter — a key difference from unfiltered G120X variants that require a separate filter unit for C2 compliance. As a 0-prefix variant, this model does not include DC terminals for du/dt filter connection; for installations requiring motor-side filtering, the 1-prefix enhanced variants should be specified.

What communication and I/O does this drive provide?

The drive runs MODBUS RTU, BACnet MS/TP, and USS concurrently on the integrated RS-485 interface, enabling simultaneous communication with PLC/SCADA systems and building management networks without protocol gateways. Six digital inputs, two analog inputs, and one analog output handle speed reference, start/stop sequencing, and process variable feedback for most pump and fan installations without additional I/O expansion. An RS-232 port supports point-to-point communication for commissioning and drive diagnostics.
