The 6ES7194-2LH02-1AA0 carries I/O signals between an ET 200AL input or output module and the adjacent sensor or actuator connection point. At 0.19 m it is short enough to keep the wiring tidy, yet long enough to comfortably reach the next module in the row. The gray PVC jacket follows the ET 200AL colour convention — green for power, gray for signals — so installers and maintenance staff can trace circuits at a glance without labels or wiring diagrams.

Physical Toughness

• IP65/67: dust‑tight and protected against water jets when the M8 connectors are correctly screwed down — safe for wash‑down environments.
• Cable‑chain rated: 2.5 million bending cycles at a 52 mm bending radius, suitable for moving machine elements.
• Silicone‑free: certified for paint‑shop and clean‑room use.

Electrical Layout

• 4‑pole A‑coded: supports standard sensor and actuator signals through a single compact M8 connector.
• Pure copper conductors (4 Li9Y 0.50 mm²): ensure reliable signal transmission even in high‑noise industrial environments.
