Product Specifications

Product Description

The head transmitter market splits into two halves: the modules that convert a signal, and the modules a process engineer can standardize a plant on. The YTA70 from Yokogawa Electric Corporation sits deliberately in the second half, adding HART communication to the YTA50 foundation and carrying the qualification papers serious projects ask for.

Why does the input list decide the standardization argument?

Because every thermowell in the plant becomes the same spare part. Seventeen input types are selectable in the field: thermocouples B, E, J, K, N, R, S, T plus L and U to DIN 43710, GOST Lr, and the W3 and W5 variants, RTDs in Pt100 and Ni100 across 2, 3 and 4-wire connections, ohms and DC millivolts, each linearized to the two-wire 4-20 mA output with burnout behavior per NAMUR NE43 in upscale, downscale or a custom window. Accuracy lands at plus or minus 0.1 percent of span or 0.1 degrees C on Pt100, with input-output isolation of 1500 VAC, and HART runs as revision 5 or selectable 7 with long tags, enhanced burst mode and event notification, configured through FDT/DTM technology. The response time programs from 1 to 60 seconds, zero offset reaches plus or minus 50 percent of span, and the supply window of 8 to 35 VDC with 13.8 minimum for digital communication keeps the loop arithmetic honest. Mechanically it fits DIN Form B heads, number 2 or 9, with an adapter plate for number 5, or a DIN rail, all at 50 grams across -40 to +85 degrees C. Against regional transmitters whose certifications stop at the border, the YTA70 argument is 17 inputs, two HART revisions and ATEX, FM and IECEx papers from a maker whose field instruments run the plants this module reports to.

Yokogawa
Compare

Yokogawa YTA70 head mount transmitter with 17 input types and HART 5 or 7

Yokogawa YTA70 transmitter
MPN/Series: YTA70

Product Specifications

Brand
Yokogawa Electric Corporation
Part Number
YTA70
Type
head mount HART temperature transmitter
Series
YTA family
Inputs
17 selectable types, TC/RTD/ohm/mV
Output
4-20 mA, HART 5 or 7
Accuracy
±0.1% of span or ±0.1°C RTD
Isolation
1500 VAC input/output
Mounting
DIN Form B head, rail, 50 g
