The IC758CSWA12PC128 is a 12.1-inch industrial panel PC in Emerson's PACSystems RXi family — a full Windows 10 IoT computing platform in a fanless, IP66-sealed enclosure. Powered by an AMD Embedded GX-412GC quad-core processor with 4 GB of ECC DDR3L memory and a 128 GB SATA Slim SSD, it runs the full Windows 10 IoT Enterprise LTSC operating system, supporting the same software stack as a desktop industrial PC while mounting directly on the machine or enclosure door.

What distinguishes the IC758C panel PC from the IC757C web panel?

The IC758C series is a full x86 Windows panel PC, while the IC757C is an ARM-based embedded web panel running Linux Yocto. The IC758C runs Windows applications locally — SCADA runtimes, programming tools, databases, and custom software — and connects to controllers over Ethernet. The IC757C renders web-hosted HMIs from a remote server. Choose the IC758C when local computing power or Windows software compatibility is required; choose the IC757C for centralized, browser-based HMI architectures.

What I/O and expansion does this model provide?

Network connectivity includes four independent Gigabit Ethernet ports, supporting simultaneous connections to control networks, enterprise LANs, and camera or I/O subnets. Two USB 3.0 and two USB 2.0 ports accommodate peripherals, while isolated RS-232 and RS-485 serial ports connect to legacy automation equipment. An internal Micro SD/SDHC slot provides up to 32 GB of removable storage. The modular design allows post-purchase computing unit upgrades — RAM up to 16 GB and dual or quad-core processor options are field-replaceable.

How does the display perform in industrial conditions?

The 12.1-inch WXGA (1280 × 800) display delivers 400 cd/m² brightness with 176° horizontal and vertical viewing angles and an 800:1 contrast ratio. The PCAP touchscreen supports 10-point multi-touch and works with gloved hands. LED backlighting is software-dimmable and rated for 50,000 hours MTBF at 25 °C. The IP66/UL Type 4X front seal protects against dust, moisture, and direct water jets.
