The 6SL3520-1XN01-5AF0 delivers 1.5 kW in the G115D 1XN-variant FSA frame with AF-suffix PROFINET — the fieldbus-equipped fanless modular drive for SIMATIC-controlled decentralized conveyor systems. Rated 4.1 A continuous (8.2 A peak at 200% overload), it integrates PROFINET communication directly on the drive, appearing as a configured device in the SIMATIC project tree with cyclic data exchange and diagnostic telegrams. The 1XN FSA enclosure (380 × 216 × 129 mm) mounts directly on the conveyor frame with IP65/IP66 protection and natural-convection cooling.

The 1XN modular electronics platform enables drive replacement in under 15 minutes without disturbing field wiring — the replacement module plugs into the same terminal block and connector set. For airport baggage handling, distribution center sortation, and automotive assembly lines, this minimizes conveyor downtime. Standard G115D features apply: 200% overload for 3 s, integrated C2 EMC filter, internal braking chopper, STO SIL 2, and SAM web-server commissioning.
