Product Specifications
- Manufacturer
- AquaMetrix
- Product Number
- 2250TX Series
- Product Type
- Loop-Powered Multi-Parameter Transmitter
- Supported Parameters
- Conductivity, pH, ORP, Flow
- pH Range
- 0 to 14 pH
- ORP Range
- ±999 mV
- Conductivity Range
- 0.055 to 100,000 µS/cm
- Core Control
- PID control
- Signal Outputs
- Two 4-20 mA outputs with range scaling
- Power Supply
- Loop-powered device
- Core Features
- Tool-free flexible calibration, intuitive no-manual user interface
- Primary Applications
- Industrial Process Control, Municipal Water/Wastewater Treatment, Fume Scrubbers, HVAC/Cooling Towers/Boilers, Plating, Food & Beverage, Chemical Processing, Pulp & Paper, Mining
- Documents
- Product Manual , Product Specs
Product Description
The AquaMetrix 2250TX Series Flow Transmitter is designed to be the most flexible, easy to use, and easy to see multi-parameter transmitter on the market. The 2250 Series allows you to choose Conductivity, pH, ORP or Flow. The user interface was designed under the principle that the user should not need to read the manual.
Applications for the 2250 Series include:
- Industrial process control, e.g. plating, food and beverage, chemical processing, pulp & paper, mining, food and beverage
- Municipal water and wastewater treatment
- Industrial and Municipal Waste treatment and Neutralization
- Fume scrubbers
- HVAC, cooling towers and boilers
Features
- pH, ORP, conductivity & flow parameters available
- Integrated PID control function
- 0 to 14 pH measuring range
- ±999 mV ORP measuring range
- 0.055 to 100,000 µS/cm conductivity measuring range
- Flexible and easy field calibration
- Two 4-20 mA outputs with user-configurable range scaling
- Loop-powered device design
