The 6SL3520-1XD00-5AF0 is the PROFINET variant at 0.55 kW in the 1XD D-connector SINAMICS G115D family — the lowest-power G115D configuration combining PROFINET IO with the D-connector interface. It delivers 1.7 A HO (3.4 A LO) in the FSA compact frame (380 × 156 × 129 mm, ~4.7 kg) with natural convection cooling at 380–480 V three-phase. The AF0 interface provides PROFINET IO with PROFIsafe, EtherNet/IP support, and an integrated 2-port switch for daisy-chain line topology and MRP ring redundancy — all on the same Ethernet cable. Compatible with IE2/IE3/IE4 motors across 0–550 Hz, IP65 sealed.

Why choose D-connector with PROFINET at 0.55 kW?

The D-connector + PROFINET combination gives the lightest networked drive node in the G115D wall-mounted range. For a distributed conveyor system where every zone motor is 0.55 kW or less, the D-connector provides a compact single-cable power+communication interface while PROFINET delivers coordinated multi-drive control with safety over the same Ethernet cable. The 0.55 kW rating means no oversized drive sitting on a light load — each drive is right-sized to its motor, reducing panel space and cost in high-count distributed installations.
