The 6SL3520-1XK00-5AB0 is the entry point to the 1XK wide-voltage series: 0.55 kW at 1.7 A, FSA frame, integrated braking chopper, and the 1/3-phase input stage that defines the 1XK family. As the smallest and lowest-power variant in the range, this drive serves single-roller or auxiliary conveyor sections where the motion profile is simple but the installation environment demands the same IP65 sealed construction and wide-voltage flexibility as larger stations on the same machine.

The entry point with braking capability

Even at 0.55 kW, a drive on a stop gate or diverter sees hard stops every few seconds. The AB0 integrated braking chopper with internal resistor handles these load cycles without requiring an external resistor enclosure — the entire drive, including its braking capability, fits within the FSA sealed aluminum housing. For the OEM designing a compact machine where every component must earn its volume, an integrated solution that handles both motoring and braking in one IP65 package eliminates the external brake resistor as a separate design constraint.
