The Dakota NDT PMX2-DL thickness gauge displays thickness values with A‑Scan and B‑Scan displays. The auto find feature locates detection points and adjusts display settings to bring the waveform into view. User‑selectable resolution of 0.01mm or 0.001mm (0.001/0.0001 inches).

High speed scan takes 250 measurements per second, speeding up inspections. The transducer can be removed to display the minimum measurement scanned. Limits can be set for individual readings or batches with audible/visual alarms. Measurement modes: Pulse-Echo, Echo-Echo, Echo-Echo Verify, Interface-Echo, Interface-Echo-Echo. Square wave pulser with adjustable pulse width (spike, thin, wide). Receiver gain range 110dB (manual or AGC).

4GB internal memory stores readings and waveforms. Display modes: A‑Scan (±Rectified, RF), B‑Scan, Large Digits, Scan Bar, Bar Graph. B‑Scan speed 10–200 readings/sec. 64 custom user‑defined setups. 1/8 VGA grayscale display. Factory calibration traceable to NIST & MIL‑STD‑45662A.
