The R2U2N1C0B2T0F is a maximally configured RXi2-UP at the 32 GB memory tier, built on the bCOM6L20 COM Express module with a 7th Generation Intel quad-core processor — either Xeon E3 or Core i7 class — on the CEC09 carrier board. The "2" in the slot position designates 2 PCIe expansion slots via the PERC10 riser, and the "F" suffix indicates Windows 10 IoT pre-installation. This configuration targets the most demanding consolidated workloads in factory automation: running a soft PLC, SCADA visualization, and analytics simultaneously on one device.

What does the slot count mean for real-world deployment?

Two PCIe slots enable card pairings that single-slot platforms cannot support: a motion control card plus a fieldbus interface, a frame grabber plus a dedicated GPU, or redundant network interface cards for high-availability architectures. Combined with 5 onboard Gigabit Ethernet ports — 4 with IEEE 1588 time sync — the R2U2 configuration can serve as a centralized cell controller managing real-time I/O, safety communication, and plant network uplink from a single fanless chassis. For applications that need PCIe expansion but favor the UP's Intel ecosystem over the XP's larger chassis, the 2-slot UP is the highest-performance RXi2 option before moving to the XP platform.
