The IC755CBW07CDA is a 7-inch widescreen QuickPanel+ operator terminal from Emerson, representing the next-generation display in the QuickPanel+ family with a projected capacitive (PCAP) multi-touch screen. Like all QuickPanel+ models, it integrates HMI visualization, a full IEC 61131-3 PLC runtime, and a data historian in a single panel-mount device — but the 7-inch widescreen format and PCAP touch bring this 3-in-1 architecture to applications needing a larger, more responsive display than the 6-inch resistive models.

How does the 7-inch widescreen PCAP model differ from the 6-inch resistive QuickPanel+?

Two key differences distinguish this model from the IC755CxS06 series: display and touch technology. The 7-inch widescreen LCD offers 800 × 480 WVGA resolution — more than triple the pixel count of the 6-inch 320 × 240 QVGA panel — providing more screen real estate for complex HMI screens, trend graphs, and multi-pane layouts. The PCAP touchscreen replaces the analog resistive overlay with a glass capacitive surface, supporting 2-point multi-touch gestures and offering the durability and optical clarity benefits of capacitive technology — no pressure-sensitive layers to wear, brighter image transmission, and reliable gloved-hand operation.

What does the blank bezel configuration mean?

The "B" designation (CBW) indicates a blank bezel — the standard QuickPanel+ configuration without an integrated fieldbus interface. This model connects to controllers and I/O via its 10/100 Ethernet and RS-232 serial ports, supporting multi-vendor protocols. For applications requiring native RSTi-EP Modbus TCP connectivity to Emerson's distributed I/O platform, the IC755CKW07CDMEP variant adds that fieldbus interface. The blank bezel model is the right choice when the QuickPanel+ communicates over standard Ethernet and serial protocols to third-party PLCs, drives, and I/O.
